Features and Benefits:
- Color: Red/Black
- Capacity: 10 Ton
- Minimum Height: 6.7"
- Maximum Height: 23"
- Power Type: Hydraulic
- Operation Type: Manual/Foot Pedal
- Quick Lift Feature: Oversized Pump Piston for More Flow
- Working Air Motor Pressure: N/A
- Release Assembly: U-Joint
- Chassis Type: Long Chassis Service Jack
- Chassis Length (in.): 61"
- Chassis Width (in.): 13.1"
- Handle Type: T-Handle
- Handle Length (in.): 40"
- Handle Type (Pcs): 1
- Saddle Size: 6.2"
- Includes Saddle Pad: No
- Saddle Pad Material: N/A
- Handle Bump Protector: No
- Rear Casters: Qty 2
- Front Wheels: Qty 2
- Hydraulic Return Spring: Yes
- Overload Bypass Valve: Yes
- Handle Return Spring: No
- Handle Docking Position: 90°
- Handle Locking Positions: 90°/45°/180°
- Service Parts Available: Yes
- Duty Level: Heavy Duty
- Weight (lb.): 366 Lbs.
- Warranty: 1 Year
- Certification: ASME/PASE 2019
- Long 61" body for easier lifting of vehicle with long overhangs.
- Foot-operated pump for quick lifting efficiency. Handle-mounted control lever to lock handle in 1 of 3 positions.
- Automatic overload safety valves.
- Swivel casters for ease of maneuverability in tight shop situations.
- Extra-wide stance for additional stability.
Designed with the professional service technician in mind, AFF service jacks are built to withstand the rigors of everyday use and are among the most durable in the industry today. Heavy gauge steel, UV powder coated paint, upgraded seals and overload protection are just some of the features that make AFF service jacks stand out in the shop.
